Single Ended Triode Stereo Power Amplifier (MK3)
DESIGN NOTE :
With James transformers stopped supplying HiFi transformers, we need to end the MK2 prematurely. And that gives us the opportunity to design/manufacture our own HiFi specs of transformers inhouse here in Canada, for the new 2A3S-III.
While we already mastered the design and made the 2A3S the best sounding 2A3 SET amp around the world, we hate to call it a new generation without a larger change. Some basic history - the MK1 was only sold hand-wired throughout, the MK2 is the same but put on PCB as we expanded our sales/production and safer shipping.
As we put the MK3 into production, rather than make it even better - there is no better, since we already mastered the sound/circuit on the MK1/2. There are a few more small items we can improve in terms of efficiency and streamlining. To begin the changes, since the size of the output transformers and choke transformer are enlarged, the big power supply ECAP no longer available has the space (some safety jurisdictions not approved anyway). This means that, we have to put it on to the PCB too. While we undergo the surgery, now we know the exact parts (the physical size of the parts what we really mean) we will be using, we can also refine the entire PCB better and more efficient... Here are the changes / updates:
1. Whole pre-amp/driver section redesigned - better locations (from input to exit)/channeling (flow one-way instead going point C then come back to point A...etc)/rearranged parts to shorten distance to max (that's mean minimized path and lowest possible interference)
2. Better isolation between pre-amp (input amp) stage TO power output stage to minimize cross-talk/interference/heat transfer...etc.
3. Better/reworked/beefed up grounding everywhere applied - Preamp stage, Power Output stage, Power Supply stage (we just know where to ground best to improve the quality of sound)
4. Power output section redesigned as well: better relocations, more venting, more spacing, better in every way...
5. Redesigned better power supply stage - multi-caps approach, centralized power supply section (now Choke and ECaps into one little section versus previous wired into different locations), rectifier tube socket now can uses chassis mounting type to minimize the chance in voltage leak, interference and better heat dissipation, we also added an extra fuse for further protection in case of inserting the 2A3 with wrong pins to minimize possible damage (happens quite often when we have a drink in our hands and the lighting is dim).
With all these updates and changes, we want something different to what is already considered the best.
While we already mastered the design and made this the best sounding 2A3 SET amp around, we hate to call it another generation.
Some basic history - the MK1 was only sold handwired thru-out before Y2K, the MK2 is the same but put on PCB as we expanded our production and safer shipping.
- Rated Output : 3.5W + 3.5W
- Operation : Class A Autobias
- Speakers Outputs : 8 Ohms (16 Ohms as Options)
- Total Harmonic Distortion : Less than 1% at THD + N @ rated power
- Hum & Noise (A-Weight) : 80 db or better at rated output
- Frequency Response : 20 Hz to 20 Khz +/- 1 db
- Output Tubes : 2A3 Matched Pair
- Preamp Tubes : 6SN7 Pair
- Rectifier Tubes : Thanks to our "Uni-Fy" Rectifier Stage Design, most rectifier tubes will work, except GZ37 and 5AU4 - warranty voided if used. Our reference / favourite are the 5V4 / GZ32
- Triode Lab P-10 Output Transformers, 10W, Engineered for 2A3, M6 Material, Made in Canada
- Hammond Canada Choke and Power Transformers (CSA/UL/CE Compliance)
- Mundorf Silver Oil Caps
- CMC Gold RCA
- Furutech Gold AC Inlet
- Premium Gold Pins Tube Sockets / Insulated 5 Way Binding Posts / High spec Japanese ECAPS / Brand name resistors ...etc
Model: 2A3S - FFX
FFX - the top-of-the-line 2A3S, some considered it as the best compact stereo 2A3 SET amp available on the market, also our bestseller. It will continue to be sold and built, carried over from the MK2 design - it is perfect (tone, performance, and measurements) and we do not wish to make any possible change to the unique voice of the FFX. This will be a future classic, a collectable design.
- Further upgrades with Hashimoto Output Transformers and Choke( 3+ OPT to choose, from 3.5W - 5W+ ) These are the finest exotic grade transformers from Tokyo, Japan, whom used to OEM supply for Sansui.
- Triode Lab 2A3-FFX M6 Power Transformer (Same one used on the 2A3GT-FFX) or Hashimoto Power Transformer (Standard 2017+)
- Choice of: Triode Lab's Official Colours, or your own choice of computer coded automotive paint
- Mundorf Silver in Oil Caps for the 2A3s
- Mundorf M Lytics HV Power Supply E Cap
- Furutech Gold RCA, or your preferred RCA
- Cardas Binding Post, or your preferred post
- Furutech Rhodium IEC Inlet
- 100% tailor to customer, like "haute couture" of fashion
Starting: $4,800+ Options
- Limited. Made-to-order only. Lead time required.
- 2A3S-FFX R on Pure copper chassis available $6,500 USD - Big 20W OPT Potted Hashimoto Output Transformers
Feedback and reviews from two 1st time TRIODE LAB buyer: (100% Direct copy from emails)
All my apologies for not getting back to you earlier with feedback about the 2A3-S amplifier: the tubes took almost two weeks to arrive due to the Easter holiday period. I've only been able to listen to it during the last few days.
As a reminder they're connected to my Zu Audio Soul Supreme speakers (16 ohm and 101db/W) and I'm using Tung-Sol 6SN7 drivers, EH 2A3 Gold power tubes and a Svetlana 'C' logo 5U4G rectifier tube. I also have a pair of EH 6SN7 drivers and a Mullard GZ32 rectifier tube to try later.
First I would like to let you know that I like a lot the white car paint finish: it looks perfect.
I've been listening to various kind of music on the amp from small jazz quartets to electronic music and I must admit that I'm really impressed with the results. Instrument textures and voices are incredibly smooth and the dynamics (especially on drums or percussions) are out of this world. In particular the difference between the 8 and 16 ohm switch is a must have because the output is way stronger on the 16 ohm connection, sound stage is better, everything opens up much more. I think the simpler non active Zu speakers (the Soul and the Druid) are a really good match to your amp.
The other aspect that I'm impressed by is the bass. Most of the 300B or other SET amps have weak flabby bass but not the 2A3-S! All bass instruments sound deep and tight as they should and redefine what bass can be with a properly designed SET amp. Hats off!
I also would like to let you know that noise and hum are for all purposes non existent - even with the ear stuck on the driver one can only hear the faintest hum on 100+db sensible speakers: well done! The only missing thing would be some kind of manual with recommendations about tubes and basic instructions about how to connect the amplifier or switch output impedance.
To sum it up, I'm extremely satisfied with my purchase of the 2A3-S. For the price I think it's an outstanding product and with the Hashimoto OPT it's really a joy to listen to.
Best regards from Switzerland!
"I installed the 2A3FFX with Sylvania 5U4GB, PSVANE WE274, and NOS 6SN7s. I used the MDA-1000 to feed it via an Oppo player for a transport. Cardas Clear single ended interconnects. Analysis Plus Oval 9 speaker cables to the Avantgarde Duo Omegas. I use a balanced (center tapped) transformer to power all components except for the woofers, which are fed directly from the dedicated 20A circuit for the system.
Using the 2A3FFX, the sound has texture. There is something about the 2A3s that give the sound a palpable quality. It seems at ease, without being smoothed over or dull. I am able to relax and just listen to lots of music with this setup. There is all the detail that I am used to, but without it being etched or sharp. The bass is firm and solid, but not as quick or detailed as solid state amplification. But texture is the main strength, I have never heard such realistic texture and tone. Overall, the amp is more pleasurable to listen to than any I have heard before, quite an impressive feat!!!
From Rush Battle, Texas USA"
And if you want more power around with 2A3 tubes, we also have the 8 Watts 2A3SE-PSDM (Parallel Stereo Dual Mono configuration) version for our 2A3 connoisseurs.
Pure dual mono design, each channel's own output, choke, power transformers and tube rectified power supply stage on to the same chassis - Total 6 Transformers.
DUO Feedback Technology , exclusive and debut on this 2A3 Parallel SE Design. Double the bandwidth, higher efficiency and stability, lower distortion and noise, and beautiful curves of both measurements and image of the body.
Feature using Mundorf flagship MTUBECAP power supply capacitor (Its big!) - Our design uses one big capacitor over multi-piece of E caps for better S/N ratio and fewer chances of interference. What's more, a long duration of R&D of the layout and location on each (out of 6 pcs of transformers) is carefully measured and tested, to ensure each spot where the transformer is mounted is the quietest place to be. Even the horizontal/vertical placement of each transformer make a difference, if you notice how we handle the transformers on the chassis.
Mundorf Supreme Silver in Oil Caps are voiced and used across the range
Chassis and tubes same as 2A3 SET Integrated, 6SL7 will be used if doing the PSDM as in integrated. 5U4 AND GZ32/5V4 Rectifier Tubes are recommended. All ideals to be matched.
Class A 8 Watts (Conservatively under-rated), on our prototype, with One Electron USA Output Transformers, we were measured max power of 9.5Ws. The final outputs will depend on the make of transformers. Starting 2016, full suit of Canadian transformers will be used.
MSRP $5,999 USD
(USA-CAN Made Transformers/CMC USA Gold RCA/Binding Post 4 & 8 ohms/Furutech Gold AC Inlet/Mundorf Silver in Oil Caps), tubes not included in the price. Integrated version addition $1,500, 6SN7 upgraded to 6SL7. Limited. Made-to-order only. Lead time required. Pure copper chassis available.
Pricing NOT INCLUDING 3" Foam Vault/Triple Layer Carton Box/Optional Wood-crate Shipping Arrangement. 60 lbs+
2A3-PDSM FFX :
MSRP $12,999 USD Power Amp / $13,999 USD Integrated
Complete suit of Hashimoto (Sansui) Transformers. Limited. Made-to-order only. Lead time required. Pure copper chassis available.
- Your choice of Porsche or Mercedes Benz paint or copper chassis.
- NEW FLAGSHIP OUTPUT TRANSFORMERS DESIGN BETWEEN TRIODE LAB X HASHIMOTO - Newly developed for Parallel 2A3/300B/45
- DACT / ELNA / TKD Grade Vol Control / Selector Switch
- DH LABS USA Gold RCAandFurutech Carbon Fibre Binding Posts
- Mundorf High End Caps/ Furutech Gold AC Inlet / CMC USA 2A3 Tube Sockets / QQQ Japan Industrial Grade Tube Socket (Rectifier Tube)
Pricing NOT INCLUDING 3" Foam Vault/Triple Layer Carton Box/Optional Wood-crate Shipping Arrangement. 60 lbs+
| Having the first Triode Lab 2A3-PSE stereo amp was an honour, and using it was a joy. The amp consistently made me smile; it made me want to rifle through my records to find more music to play. I enjoyed every aspect of this amp, and I’d consider it a worthy addition to most any high-end domestic audio system. I was sad to see it leave – I don’t know when another component of this caliber might grace my room. Very highly recommended.|
Is there an end? - ask for a 2A3-RS
- Your choice of 12AX7 or 6H30 as drivers
- Power output : 2A3 - min 4W max output power (depending brand / model of transformers)
- The 12AX7 version is handmade in our usual top notch 3D classic hard-wiring ; 6H30 version required a more complicated design and required to perform best on a circuit board that is entirely grounded/shielded for the best result. We've mastered this tube over a long period of time and even though this tube required more attention and work, we just like the sound of it. Either driver-stage uses finest resistors and e-caps, and via industry best QQQ-Japan's tube socket
- Your choice of: Hammonds or Hashimoto Transformers Set
- Dual Choke Transformers (One supply the operation and one supply the tubes) following its dedicated high quality dual Mundorf MLytic Ecaps
- Chassis size : 18" W x 12" D x 2" H
- Pure Copper Chassis ($1,000 Extra) , finished in a semi-gloss lacquer for a rich and elegant presentation. The high quality copper material is much heavier than its aluminum counterpart, as well, a good conductive material for electric (there are reasons why your experienced audiophiler say its a sweet thing!), and expensive to source and fabricate (very hard material). It requires a week of dip, clean and polish right here in Toronto, before it can be sent off to our clear-coat facility with lint-free glovehandling at all time. The time, labour, and going to four different shops easily increase the value of these copper chassis north of $2K. They weigh close to 30 lbs without any transformers.
- Rectified and voiced by Mullard GZ32/ EML 274B (5U4/5V4 can be substitute, 5AR4/GZ34 not recommended on NOS/Old 2A3 and 45)
- Goodies - Finale's Pink-Gold RCA / Cardas Binding Posts, Mundorf Silver in Oil Caps, Furutech Rhodium AC IEC, QQQ Japan's tube sockets...etc.
MSRP: $8,999 USD (Hashimoto or James) / $8,999 CAD (Triode Lab / Canadian Transformers, spec)
- Limited. Made-to-order only. Lead time required.
- Pricing INCLUDING 3" Foam Vault/Triple Layer Carton Box/Optional Wood-crate Shipping Arrangement. 60 lbs +
- No tubes included!
Model: 2A3S MK2 (Discontinued 2017)
Signature Version to the 2A3 Classics with the use of finer audiophile level parts and high quality tube transformers (now unavailable), and to finish with automotive paint to have your own unique SET amp.
Special Features :
- James Output Transformers (Power boosted to 4 watts, 4.3 watts @ 2% THX 8 Ohms )
- Hammond Canada Series 300 (120V-240V) Power Transformer, built specific for 2A3 amp use
- James Choke (Potted with epoxy) for superior noise filtration
- Mundorf Audiophiler ZN Fin Foil Audiophiler Coupling Caps (Recommended)/or upgrade oil types Caps for the higher-efficiency speakers.
- JJ Tesla Power Supply E Cap (Optional Mundorf M-Lytic ECap - quieter)
- Furutech Japan IEC Gold Inlet
- Cardas or CMC USA RCA Connectors
- Cardas Gold Binding Post (Optional)/CMC USA Gold Binding Post
- Triode Lab Orange/Triode Lab Satin Black/Triode Lab Classic Dark Gray Gloss, or custom paint for extra 3 months wait.
Starting: $3,800 USD
Plus Options / Customs available
Not only is the 2A3-S the "little engine that could", Triode Lab is the little company that can.
2A3S Signature REVIEW by Mr. Rick Becker of Enjoythemusic.com (Click above picture to read full review)
Model: 2A3 Classic
Single Ended Triode Stereo Power Amplifier (MK2)
This is our second generation 2A3 SET design, which replaces the original 2A3S, which debuted in 2002 (MK1), using hand-wire construction throughout. Although those days were a 300B era, we just loved the 2A3 more. And by any standard worldwide, this is what we call a good 2A3 design. It took us a few years to fine tune the sound on this MK2 2A3SET, and now we really like how it is voiced. Furthermore, we are heating it with AC, and we are happy with the quiet result. Running DC (the path most designers take) is quieter on paper, but it just doesn't sound better than AC. The comparison is much like Analogue (AC) versus Digital (DC). And our 2A3SET is quieter than many SET amps out there heated with DC. (Pictures on lower row, are the original MK1, with the James output/choke transformers)
Review by Rick Becker of Enjoythemusic.com:
"We put the CD into forward, listened for a brief moment, looked at each other and simultaneously broke out into laughter. This is a seriously good amplifier in spite of its humble appearance. The top end is rolled off. The presentation is dark, being centered on the lower mid-range with a full, sumptuous bass. Attack is good, decay is long, mid-range focus is very good and the holographic music grabs your gut and pulls you right into the collective soul of the performers."
"These could be the 3.5 most important watts on the planet."
